Control valves for every application
Bronkhorst control valves can be furnished as an integral part of a mass flow controller, a pressure controller, or as a separate component in combination with a gas or liquid flow or pressure meters. The proportional, electro magnetic control valves feature fast and smooth control characteristics. With reference to the specific fields of application there are different series of unique Bronkhorst® control valves.
Products
F-021
Flow up to approx. 50 ln/min
Pressure up to 64/100/200 bar
Kv-max: 6.6 x 10-2
F-004B
Flow up to approx. 1000 ln/min
For low (differential) pressure applications
Kv: 0.03...1.0
F-001
Flow up to approx. 50 ln/min
Pressure up to 64/100/200 bar
Kv-max: 6.6 x 10-2
W-001
Injecting liquid into carrier gas flow
Pressure up to 100 bar
Kv-max: 6.6 x 10-2
W-003
Injecting liquid into carrier gas flow
Pressure up to 100 bar
Kv-max: 6.6 x 10-2
F-002A
Up to approx. 500 m3n/h
Pressure up to 64/100 bar
Kv: 0.04...6.0
V30I
Flow up to approx. 50 ln/min
Pressure up to 64/100/200 bar
Kv-max: 6.6 x 10-2
F-004A
Flow up to approx. 1000 ln/min
For low (differential) pressure applications
Kv: 0.03...1.0
C5I
Direct acting valve
Pressure rating 64/100 bar
Kv-max: 6.6 x 10-2
F-011
Flow up to approx. 50 ln/min
Pressure up to 64/100/200 bar
Kv-max: 6.6 x 10-2
F-033
Flow up to approx. 100 ln/min
Pressure up to 400/700 bar
For high (differential) pressures applications
F-042
Flow up to approx. 100 ln/min
Pressure up to 400/700 bar
For high (differential) pressures applications
FLOW-CONTROL Series
Gas flow up to 50 ln/min
Liquid flow up to 1.8 l/min
Operating pressure up to 10 bar(g)
F-003A
Up to approx. 500 m3n/h
Pressure up to 64/100 bar
Kv: 0.04...6.0
F-003B
Up to approx. 500 m3n/h
Pressure up to 64/100 bar
Kv: 0.04...6.0
C2I
Direct acting valve
Pressure rating 64/100 bar
Kv-max: 6.6 x 10-2
W-002
Injecting liquid into carrier gas flow
Pressure up to 100 bar
Kv-max: 6.6 x 10-2
Technical specifications
Technical specifications subject to change without notice.
Measurement & Control
Operating Temperature
-10...+70°C, except F-001AX / F-011AX: -10...+65°C
Approvals
Marking
CE
Downloads
Manuals
-
PDF
Manual FLOW CONTROL Series (9.17.115)
Brochures
-
PDF
Brochure FLOW ADJUST
-
PDF
Brochure FLOW CONTROL
