Technical specifications
Type Of Media
Gases
Flow measuring principle
Thermal
Series range
For 0.16 mln/min - 11000 m3n/h
Accuracy
±1% FS (incl. linearity, based on actual calibration)
Repeatability
< ±0.2% Rd
Max. Pressure bar(g)
400
Operating Temperature
EX-FLOW sensor: -10…+70°C; XB-coil: -40…+ 65°C XC-coil: -40…+ 65°C
Ingress Protection
IP65
EX-FLOW models
Gas mass flow instruments with a rugged design for hazardous areas, particularly designed for industrial applications.
Search for a model
min. 0,4…20 m3n/h
max. 4…200 m3n/h
40 bar(g)
min. 1…50 m3n/h
max. 10…500 m3n/h
40 bar(g)
min. 2…100 m3n/h
max. 20…1000 m3n/h
40 bar(g)
min. 3.6…180 m3n/h
max. 36…1800 m3n/h
40 bar(g)
min. 8…400 m3n/h
max. 80…4000 m3n/h
40 bar(g)
min. 14…700 m3n/h
max. 140…7000 m3n/h
40 bar(g)
min. 22…1100 m3n/h
max. 220…11000 m3n/h
40 bar(g)
min. 0,4…20 m3n/h
max. 4…200 m3n/h
40 bar(g)
min. 1…50 m3n/h
max. 10…500 m3n/h
40 bar(g)
min. 2…100 m3n/h
max. 20…1000 m3n/h
40 bar(g)
min. 3.6…180 m3n/h
max. 36…1800 m3n/h
40 bar(g)
min. 0.15...7.5 mln/min
max. 0.18...9.5 mln/min
100 bar(g)
min. 0,1…5 ln/min
max. 2…100 ln/min
100 bar(g)
min. 0.3…15 mln/min
max. 0.4…20 ln/min
100 bar(g)
min. 0.8…40 ln/min
max. 5…250 ln/min
100 bar(g)
min. 4…200 ln/min
max. 25…1250 ln/min
100 bar(g)
min. 0,4…20 m3n/h
max. 4…200 m3n /h
100 bar(g)
min. 1…50 m3n/h
max. 10…500 m3n/h
95 bar(g)
min. 0.15… 7.5 mln/min
max. 0.18…9.5 mln/min
200 bar(g)
min. 0.3… 15 mln/min
max. 0.4…20 ln/min
200 bar(g)
min. 0.8… 40 ln/min
max. 4…250 ln/min
200 bar(g)
min. 4… 200 ln/min
max. 25…1250 ln/min
200 bar(g)
min. 0,4…20 m3n/h
max. 4…200 m3n/h
200 bar(g)
min. 1…50 m3n/h
max. 10…500 m3n/h
200 bar(g)
min. 0.15…7.5 mln/min
max. 0.2…10 mln/min
400 bar(g)
min. 0.3… 15 mln/min
max. 0.4…20 mln/min
400 bar(g)
min. 0.3…15 ln/min
max. 5…250 ln/min
350 bar(g)
min. 4…200 ln/min
max. 25…1250 ln/min
400 bar(g)
min. 0.4…20 m3n/h
max. 4…200 m3n/h
400 bar(g)
0.19…9.5 mln/min
64 bar(g)
min. 0.1…5 ln/min
max. 2…100 ln/min
64 bar(g)
min. 0.3…15 mln/min
max. 0.4…20 ln/min
64 bar(g)
min. 0.6…30 ln/min
max. 5…250 ln/min
64 bar(g)
min. 4…200 ln/min
max. 25…1250 ln/min
64 bar(g)
min. 0.4…20 m3n/h
max. 4…200 m3n/h
64 bar(g)
min. 1…50 m3n/h
max. 10…500 m3n/h
64 bar(g)
min. 0.19…9.5 mln/min
max. 0.2…10 mln/min
100 bar(g)
min. 0.1…5 ln/min
max. 2…100 ln/min
100 bar(g)
min. 0.3…15 mln/min
max. 0.4…20 ln/min
100 bar(g)
min. 0.8…40 ln/min
max. 5…250 ln/min
100 bar(g)
min. 4…200 ln/min
max. 25…1250 ln/min
100 bar(g)
min. 0.4…20 m3n/h
max. 4…200 m3n/h
100 bar(g)
min. 1…50 m3n/h
max. 10…500 m3n/h
95 bar(g)
min. 0.2…10 mln/min
max. 10…500 mln/min
350 bar(g)
min. 10…500 mln/min
max. 0.2…10 ln/min
350 bar(g)
min. 0.2…10 ln/min
max. 2…100 ln/min
350 bar(g)
Downloads
Manuals
-
PDF
917028 Manual Explosion Proof Flow And Pressure Measurement And Control ATEX
-
PDF
Manual EX-FLOW IECEx (9.17.096)
-
PDF
Manual EX-FLOW TIIS (9.17.090)
Hook-up diagrams
-
PDF
Hook Up Diagram EX FLOW MFM (9.16.015)
-
PDF
Hook Up Diagram EX FLOW XC Coil (9.16.018)
-
PDF
Hook Up Diagram EX FLOW XB Coil (9.16.017)
Certificates
-
PDF
Certificate KEMA 01ATEX1172 X100 measuring head
-
PDF
EU Declaration of Conformity ATEX X100 measuring head
-
PDF
Declaration of Conformity IP65 X100 measuring head
-
PDF
Certificate IECEx DEK 14.0060 X100 measuring head
-
PDF
Certificate TIIS Certificate X100 measuring head
-
PDF
Certificate UKCA DEKRA UKEX0329 X100 measuring head
-
PDF
EU Declaration of Conformity supply unit Stahl 9260
Brochures
-
PDF
Brochure EX-FLOW
