MAG-VIEW™ magnetic flow meters for low flow rates

Compact flow meters for measuring or dosing electrically conductive liquids

MAG-VIEW™ is a compact, high quality yet economic device for measuring liquid flow rates in applications where flow sensors with moving parts cannot be applied. Its interference free operation, combined with a long-life cycle and independence to the inlet and outlet pipework, makes MAG-VIEW™ the perfect solution even in compact machines and installations. The flow meter can be used for continuous measurement or for batching and dosing applications.

  • Lowest range 0,1 ... 2 l/min
  • Highest range 5 … 250 l/min

The MAG-VIEW™ series operates on the magnetic inductive principle and is therefore suitable for electrically conductive liquids with a minimum conductivity of 25 μS/cm. The frequency of the pulse output signal is proportional to the flow. The flow meters feature fast response, low pressure drop and a weatherproof (IP65) enclosure.

Find your product

Features

  • Make liquid flows visible by pulse output, analog output (4 .. 20 mA, option on metal models only) or blinking LED (red/green)
  • No moving parts (no mechanical wear)
  • Ease of mounting and operation
  • Free pipe cross section, no additional pressure drop
  • Fast response
  • Insensitive with contaminated liquids
  • Ideal solution for interference free operation combined with a long-life cycle
  • Wide independence to the inlet and outlet pipes create the advantage to be able to install in compact machines with cramped confines.
  • Lightweight and compact design
  • Suitable for mobile applications
  • Low power consumption

afbeelding

MAG-VIEW application

Applications

  • The fields of application for this magnetic flow meter are diverse:
  • Can be used in areas where flow sensors with moving parts (paddle wheel, turbine sensors) cannot be applied due to contaminated media
  • Sensor is intended for continuously measuring of flow rates or for dosing / batching of electrically conductive liquids with a minimum of 50µS/cm
  • Water distribution
  • Chemical feed
Markets:
  • oil and gas
  • water and wastewater
  • power
  • chemical
  • food and beverage
  • pharmaceutical
  • metals and mining
  • pulp and paper.
