MASS-STREAM Thermal Mass Flow Meters / Controllers for Gases

Direct Through-Flow Measurement

The digital MASS-STREAM™ series D-6300 & D-6400 work on the basis of direct through-flow measurement, following the constant temperature anemometer principle.

  • Lowest range 0,01…0,2 ln/min
  • Highest range 200…10000 ln/min

Ask advice Request for quote

Quick link to Mass Flow Meter / Controller model pages

Mass Flow Meter model pages

Full Scale capacities (N2-equivalent) versus pressure rating

PN 20 bar
D-6310 / D-6410  |  0,2 ... 2 ln/min
D-6320 / D-6420  |  1 ... 7 ln/min
D-6340 / D-6440  |  0,7 ... 50 ln/min
D-6360 / D-6460  |  20 ... 200 ln/min
D-6360A / D-6460A  |  50 ... 500 ln/min
D-6370 / D-6470  |  100 ... 1000 ln/min
D-6370A / D-6470A  |  200 ... 2000 ln/min
D-6380 / D-6480  |  500 ... 5000 ln/min
D-6390 / D-6490  |  2000 ... 10000 ln/min


Mass Flow Controller model pages

Full Scale capacities (N2-equivalent) versus pressure rating

PN 7 bar (Kv-max) PN 10 bar (Kv-max) PN 16 bar (Kv-max) PN 20 bar (Kv-max)
      D-6311 / D-6411  |  0,2 ... 2 ln/min (0.066)
      D-6321 / D-6421  |  1 ... 7 ln/min (0.066)
      D-6341 / D-6441  |  7 ... 50 ln/min (0.066)
D-6361/FAS / D-6461/FAS  |  20 ... 200 ln/min (0.17)     D-6361/002BI / D-6461/002BI  |  20 ... 200 ln/min (0.35)
  D-6363/004BI / D-6463/004BI  |  20 ... 200 ln/min (1.0)   D-6363/002AI / D-6463/002AI  |  20 ... 200 ln/min (0.4)

      D-6361A/002BI / D-6461A/002BI  |  50 ... 500 ln/min (0.35)
  D-6371/004BI / D-6471/004BI  |  100 ... 1000 ln/min (1.0) D-6373/BJ-1-2 / D-6473/BJ-1-2  |  100 ... 1000 ln /min
(1.1 / 3.4)
D-6373/002AI / D-6473/002AI  |  100 ... 1000 ln/min (0.4)
    D-6373/BJ-1 D-6473/BJ-1  |  100 ... 1000 ln /min
(2.8 / 4.4)

      D-6371A/003AI / D-6471A/003AI  |  200 ... 2000 ln/min (2.2)
    D-6383/BJ-1-2 D-6483/BJ-1-2  |  500 ... 5000 ln /min
(1.1 / 3.4)
D-6381/003AI / D-6481/003AI  |  500 ... 5000 ln/min (2.2)
    D-6383/BJ-1 / D-6483/BJ-1  |  500 ... 5000 ln /min
(2.8 / 4.4)
D-6381/003BI / D-6481/003BI  |  500 ... 5000 ln/min (6.8)
      D-6391/003BI / D-6491/003BI  |  2000 ... 10000 ln/min (8.2)

Features

  • Virtually insensitive to moisture or particulates
  • Low pressure drop
  • Standard accuracy: ± 1.0% RD plus ± 0.5% FS (at calibration conditions)
  • Rangeability up to 1 : 100
  • Rugged, weatherproof housing (IP65, dust and waterproof)
  • Analog or digital communication (RS232 or fieldbus interface)

Video MASS-STREAM Thermal Mass Flow

Video animation explaining the functions and features of Bronkhorst's MASS-STREAM Mass Flow Meters and Controllers for gases, following the direct through flow measuring technique.


IP65 design with optional multi-functional and multi-colour display

The instruments have IP65 protection as a standard and are operated with a main-board with all functions for accurate flow measurement and control. They can be supplied with commonly used digital or analogue input/output signals. Along with the standard RS232, CANopen®, DeviceNet™, EtherCAT®, PROFIBUS DP, PROFINET, Modbus RTU, ASCII or TCP/IP, EtherNet/IP, POWERLINK or FLOW-BUS are available as an option.

One key element and innovative improvement is the optionally integrated, modern, multi-functional and multi-colour display, fully IP65 compliant with operator buttons on the instrument. With its multiple functions, such as actual flow indication, totalisation and alarms, MASS-STREAM™ series D-6300 and D-6400 offer an excellent price-performance ratio. The instruments are suitable for application in laboratories, production machinery as well as industrial installations.

Read more about direct through-flow principle

Downloads

Brochures
MASS-STREAM D-6300 Brochure
MASS-STREAM D-6400 Brochure

Manuals
Manual MASS-STREAM D-6300 instruments
Manual MASS-STREAM D-6300 display
Manual MASS-STREAM D-6400 instruments
Manual MASS-STREAM D-6400 display
Quick installation guide D-6400 series

Hook-up diagrams
Analog I-O RS232
DeviceNet
FLOW-BUS
Modbus
PROFIBUS DP with 5-pin M12 connector
CANopen
Industrial Ethernet
Optional Bus and IO Configurations
MASS-STREAM application

Applications

  • Process gas measurement in food industry, chemical and petrochemical industries, in fermentation installations and in biotechnology
  • Sample gas measurement in environmental analysis
  • Gas consumption measurement for internal accounting
  • Methane production in anaerobic digesters
  • Burners / furnaces
  • Surface treatment
  • Aeration / gas purging
  • Test benches
